The B & R Automation 2DS101.60-1 is a controller module in the System 2010 Controllers series. Powered by a RISC processor with a 0.8 μs instruction cycle, it provides 16 sink-type 24VDC inputs and 32 24VDC outputs at 0.5A. Encoder support via isolated, current-limited supply accommodates up to 16-bit SSI or 12-bit parallel resolution.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Absolute encoder interface
SSI and parallel
Base plate compatibility
BP200, BP201, BP210
Differential inputs
3 channels, RS422, max 100 kHz
Differential outputs
3 channels, RS422, max 100 kHz
Digital input switching delay
5 µs
Digital inputs
16 channels, 24 VDC, sink type
Digital outputs
32 channels, 24 VDC, 0.5 A per output
Dual-ported RAM
384 Byte SRAM
Encoder load
Max 120 mA
Encoder resolution (parallel)
Max 12 bit
Encoder resolution (SSI)
Max 16 bit (4096 steps)
Encoder supply
Isolated, short‑circuit & current‑limited
Encoder supply voltage
24 V ±10%, 4.6 V ±10%
Module type and ID
B&R 2010 I/O module, ID 1B (DS101)
Processor
RISC, 0.8 µs instruction cycle
System RAM
256 KByte SRAM
