3NC157.60-1
The B & R Automation 3NC157.60-1 module forms an integral part of the System 2005 Controllers family, designed by B & R Automation for robust industrial automation. This system module delivers 2 MB DRAM and 2 MB FlashPROM memory, enabling reliable program execution and data storage in demanding environments. With a maximum power consumption of 6 W and a 24 VDC supply voltage, the 3NC157.60-1 operates efficiently within standard plant power systems. Its primary function is to control motion axes and coordinate peripheral devices over a CAN bus network, providing seamless integration into automated production lines.
Equipped with a versatile CAN bus interface, the 3NC157.60-1 supports a maximum baud rate of 500 kBit/s and a maximum network distance of 60 m, ensuring high-speed, long-distance communication. The interface features electrical isolation to protect against noise and surges, while the 9-pin DSUB plug and optional external bus termination resistor facilitate secure, maintainable connections. As a B&R 2005 positioning module with input type: sink and two dedicated trigger inputs, it can directly interface with sensors and actuators, controlling up to 8 axes simultaneously. The inclusion of a 4-pin terminal block further enhances wiring flexibility in compact control cabinets.
Designed to perform optimally between 0 °C and 55 °C, the 3NC157.60-1 provides consistent reliability under fluctuating temperatures and environmental conditions. Its compact form and low power draw make it ideal for tight spaces and energy-conscious installations. The module adheres to established electrical standards for industrial control equipment, ensuring compatibility with existing automation architectures. By integrating advanced memory, secure communication, and precise axis control, the 3NC157.60-1 boosts system uptime, reduces wiring complexity, and delivers efficient, scalable performance for modern manufacturing and process control applications.
