4D1165.00-K06
The 4D1165-00-K06 is an advanced LCD graphic display panel from B & R Automation, engineered for industrial environments demanding high performance and visual clarity. With a 128x240 pixel resolution, it can display text across sixteen lines with forty characters each. The integrated compact fluorescent lamp (CFL) ensures visibility in different lighting conditions. Measuring 350mm x 220mm x 38.6mm, this IP65-rated panel is robust, featuring aluminum construction suitable for harsh settings. It meets IEC60068 standards for shock resistance with 15g peak acceleration, and IEC6006826 for vibration resistance with parameters of 1g acceleration across 58-150Hz. The panel offers extensive user control with 16 function keys, a numeric keypad, 14 user keys with LEDs, and five cursor keys. Suitable for operating temperatures between 0°C and 50°C, it operates efficiently with a 24VDC power supply drawing 150mA. It maintains functionality under 20%-85% relative humidity, ensuring low power consumption yet high adaptability.
