series image of 4E0011.01-K21

4E0011.01-K21

by B & R Automation
$2,340.68 - $2,340.68
$2,340.68
$2,340.68 - $2,340.68
$2,340.68
Available, Shipping Varies
The 4E0011.01-K21 Industrial Control Panel (ICP) by B & R Automation is engineered for heavy-duty applications, ensuring reliable performance and versatility. With CE and cULus E115267 certifications, it adheres to global safety standards. The panel features 16 short-stroke keys, each fitted with a yellow LED, offering a user-friendly interface with customizable labels via membrane inserts. It operates on 1.5 mA at 24 VDC, with each LED adding 3 mA, optimizing power efficiency. The panel is operational from 0°C to 50°C and can be stored between -20°C to +60°C, withstanding 5%RH to 95%RH non-condensing humidity. It meets IEC60068-2-6 vibration standards and IEC60068-2-27 shock resistance criteria, offering durability in different environments. Compact dimensions of 96mm x 96mm x 35mm make it ideal for constrained spaces. Integration with processors and the ability to connect an external AT keyboard via PS/2 socket enhance its functionality in industrial settings.
30 Day Warranty
Technical Specifications
  • Manufacturer : B & R Automation
  • Product Name : Industrial Control Panel (ICP)
  • Model Number : 4E0011.01-K21
  • Certifications : CE, cULus E115267
  • Number of Keys : 16 short stroke keys
  • LED Type : Yellow LED per key
  • Current Consumption : 1.5 mA at 24 VDC
  • Additional Current per LED : 3 mA per lit LED
  • Operating Temperature Range : 0 to 50 degrees Celsius
  • Storage Temperature Range : -20 to +60 degrees Celsius
  • Relative Humidity : 5%RH up to 95%RH non-condensing
  • Vibration Resistance : IEC60068-2-6 standard, 1g, 10Hz-58Hz, 0.075mm amplitude, 9.8m/s_ 58Hz-150Hz
  • Shock Resistance : IEC60068-2-27 standard, 15g (150ms_) on all three axes
  • Dimensions : Width: 96mm, Height: 96mm, Depth: 35mm
  • External Keyboard Connection : PS/2 socket
  • Integration Capability : Seamless with processors and system units
  • Label Customization : Membrane insertion
