4PPC50.101E-10A
The B & R Automation 4PPC50.101E-10A from the 4PPC Power Panels series is a high-performance operator interface designed for demanding industrial automation environments. Boasting a 10.1 inch projected capacitive multi-touch display with a 1280 x 800 pixel resolution, it delivers crisp, bright visuals and responsive gesture control for intuitive user interaction. Powered by a quad-core ARM Cortex-A53 processor at 1.3 GHz, backed by 2 GB DDR4 RAM, and equipped with 8 GB eMMC flash storage, this panel ensures smooth multitasking and rapid access to applications. Its primary application is to provide operators with a reliable, easy-to-use HMI solution that seamlessly integrates with modern control systems.
In terms of technical specifications, the 4PPC50.101E-10A features dual 10/100/1000 Mbit/s Ethernet ports for high-speed network connectivity and two USB 2.0 ports for peripheral expansion. Legacy devices can be integrated via one RS232 and one RS485/RS422 serial interface. The panel runs the B&R Automation Runtime operating system pre-installed, ensuring out-of-the-box compatibility with B&R controllers and software tools. A 24 VDC power supply with an input tolerance of -25%/+20% supports common industrial power variations, while the panel mount design facilitates straightforward installation in control cabinets or operator stations.
The front of the panel is sealed to IP65, protecting against dust and low-pressure water jets, while the rear meets IP20 standards. It operates reliably across an ambient temperature range of 0 °C to +50 °C, making it suitable for a variety of factory and process environments. With its rugged construction, high ingress protection rating, and comprehensive connectivity, the 4PPC50.101E-10A delivers enhanced durability and uptime. A one-year warranty further ensures long-term reliability. By combining a modern, high-resolution touchscreen, robust hardware, and flexible integration options, this power panel optimizes operator efficiency and system performance in industrial applications.
