Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bandwidth (-3dB)
3 kHz
Continuous Current
15 A @ 85 VDC
Dimensions
3.82×6.57×1.37 in (97×167×34.8 mm)
Integrator Control (torque mode)
Disabled
Load Inductance Range
200 µH–40 mH
Logic Inputs
/Enable, /POS, /NEG, /Brake, /Reset
Logic Threshold Voltage
2.5 V
Operating Temperature Range
0–70 °C (baseplate)
Peak Current
30 A @ 83 VDC
Protective Features
Short-circuit, Overtemperature
PWM Switching Frequency
25 kHz
Reference Input
Differential, 94 kΩ, 20 V max
Supply Voltage Range
24–90 VDC
Weight
1.1 lb (0.48 kg) without heatsink
