The 5221CE is a DC servo amplifier from Copley Controls’s DC Servo Amplifiers series. It delivers continuous power of ~10A @ ~173V and peak power of ~20A @ ~171V, operating over 0 to 70°C baseplate temperature. Supporting load inductance of 200 uH to 40 mH, a small signal bandwidth of 3 kHz, and featuring output short circuit protection, it ensures reliable performance in industrial applications.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bandwidth
Small signal -3dB @ 3kHz
Continuous Power
~10A @ ~173V
Dc Power
+24 to +180VDC Transformer isolated
Indicators
Normal, Power OK, Fault LED indicators
Load Inductance
200 uH to 40mH, typical
Motor Inductance Setting
Selectable with components on header socket
Operating Temperature Range
0 degrees to 70 degrees C baseplate temperature
Output Voltage
~Vout = (~HV)x(0.97) - (Ro)x(Io), Ro = 0.2
Peak Power
~20A @ ~171V
Protective Features
Output short circuit, overtemperature protection
Pwm Switching Frequency
25kHz
Reference Input
Differential, 94K" between inputs, ~20V maximum
Size
3.82 x 6.57 x 1.37 in. without optional heatsink
Watts @ Icont
54W
Weight
1.1 lb without optional heatsink
