series image of 5AC600.UPSB-00

5AC600.UPSB-00

by B & R Automation
$2,985.12 - $2,985.12
$2,985.12
$2,985.12 - $2,985.12
$2,985.12
In Stock, Ships 1 - 2 Days
The 5AC600.UPSB-00 from B&R Automation is a robust power supply module ideal for critical industrial and automation applications. It features a series configuration of six Enersys Cyclon 12 V 5 Ah batteries and an NTC resistance temperature sensor to monitor temperature fluctuations, ensuring optimal operation. The unit has a nominal voltage of 12 V, supports a maximum battery current of 8 A, and offers a 5 Ah capacity. It requires charging every 6 months in storage, with a typical recharge time of 15 hours. The unit operates effectively in extreme temperatures from -40 to 80°C and can be stored in environments ranging from -65 to 80°C. With dimensions of 104 mm x 170.5 mm x 87.5 mm and a weight of approximately 3200 g, the module allows for easy installation and reliable performance in 5 to 95% relative humidity. Proudly manufactured in Austria, the 5AC600.UPSB-00 delivers dependable power for demanding applications.
30 Day Warranty
Technical Specifications
  • Manufacturer: B&R Automation
  • Model: 5AC600.UPSB-00
  • Battery Type: Enersys Cyclon 12 V 5 Ah
  • Number of Batteries: 6
  • Temperature Sensor: NTC resistance
  • Charge Interval: 6 months
  • Typical Charge Duration: 15 hours
  • Nominal Voltage: 12 V
  • Maximum Battery Current: 8 A
  • Battery Capacity: 5 Ah
  • Deep Discharge Voltage: 10 V
  • Operating Temperature Range: -40 to 80 degrees C
  • Storage Temperature Range: -65 to 80 degrees C
  • Weight: 3200 g
  • Dimensions: 104 mm width x 170.5 mm length x 87.5 mm height
  • Humidity Range: 5 to 95% relative humidity
  • Country of Manufacture: Austria
