5AC800.EXT1-00
The B & R Automation 5AC800.EXT1-00 from the 5AC CNC Addon Modules series is a precision-engineered keypad extension designed for demanding industrial applications. Built with a focus on durability and user interaction, this component features robust design elements such as IP65 (dust and sprayed water protection) and a high-quality aluminum, naturally anodized frame. It comes equipped with a USB 1.1, Type A interface that supports both low and full speed data transfer, making it ideal for seamless integration with control systems while ensuring reliable communication in rugged environments.
Detailed technical specifications of this unit include precise dimensions of 426 mm width, 146.8 mm height, and 34.9 mm depth that promote compact installation under the Automation Panel 800 display. The extension houses an interface capable of supporting a maximum current of 500 mA and data transfer speeds of up to 12 Mbit/s, providing flexibility for peripheral connectivity. Signature LED indicators with luminous intensities of 35 mcd (green) and 60 mcd (yellow) ensure clear visual feedback in varying operational scenarios. Additionally, the keypad supports an array of alphanumeric keys, numeric keys, and a dedicated cursor block that simplifies user interaction even in complex industrial settings.
Further enhancing its industrial suitability, this unit operates efficiently with a power consumption of max 4 W and is designed to function within a wide temperature bracket from 0 to 50 degrees C. Weighing approximately 1600 g, the component offers a balanced combination of rugged construction and lightweight design, ensuring easy mounting as well as resilience to shock, vibration, and altitude changes up to 3000 meters. The structural build using Aluminum (ADC12), similar to silver metallic (semi-matt) not only provides aesthetic appeal but also guarantees durability over prolonged use. Together, these features exemplify a solution that delivers robust performance and energy efficiency, while maintaining industrial standards for protection and adaptability.
