series image of 5AC800.EXT3-K02

5AC800.EXT3-K02

by B & R Automation
$1,199.97 - $1,199.97
$1,199.97
$1,199.97 - $1,199.97
$1,199.97
In Stock, Ships 3 - 5 Days
The 5AC800.EXT3-K02 by B&R Automation is a robust keyboard expansion module in the 5AC series, designed to enhance the Automation Panel 800 with efficiency and safety features for industrial environments. This module includes 4 function keys, 12 illuminated ring keys, an E-stop switch, and a key switch, conveniently mounted on the panel's left side. It offers IP65 protection against dust and water, suitable for harsh settings. Safety is prioritized with an emergency switch-off function featuring 2 normally closed contacts and a key switch with 1 normally open contact. LED indicators provide clear status cues in Yellow, Red, and Green with varying luminous intensities. With a maximum power consumption of 8 W and an operational temperature range of 0 to 50°C, this compact, energy-efficient module measures 135 mm (W) x 330 mm (H) x 34.9 mm (D) and weighs 1100 g, making it suitable for space-conscious control panel setups.
30 Day Warranty
Technical Specifications
  • Manufacturer: B&R Automation
  • Series: 5AC
  • Model: 5AC800.EXT3-K02
  • Product Type: Panel Keyboard Module
  • Function Keys: 4
  • Illuminated Ring Keys: 12
  • E-stop Switch: 1
  • Key Switch: 1
  • Mounting Position: Left side of Automation Panel 800
  • Protection Rating: IP65
  • Emergency Switch-off Contacts: 2 normally closed contacts
  • Key Switch Contact: 1 normally open contact
  • LED Indicators: Yellow (Typ. 60 mcd), Red (Typ. 54 mcd), Green (Typ. 35 mcd)
  • Power Consumption: 8 W
  • Operational Temperature Range: 0 to 50 degrees C
  • Storage Temperature Range: -25 to 60 degrees C
  • Dimensions: 135 mm (W) x 330 mm (H) x 34.9 mm (D)
  • Weight: 1100 g
