5AP930.1906-K03
The B & R Automation 5AP930.1906-K03 is a robust Human Machine Interface from the 5AP Single Touch Automation Panels series, designed for industrial automation environments requiring reliable operator control. This unit integrates a 19.0-inch TFT color LCD with resistive touch technology to provide intuitive single-point input for menu navigation, status acknowledgment, and start/stop commands. The panel delivers a 1280 x 1024 pixel resolution that ensures sharp graphics and clear text, facilitating rapid interpretation of process data. Built to withstand industrial settings, it features an IP65 front-panel rating to protect against dust and water ingress, making it suitable for washdown or dust-prone applications. Lightweight yet rugged at Approx. 8.5 kg, the 5AP930.1906-K03 balances durability with ease of installation.
Detailed technical specifications of the 5AP930.1906-K03 highlight its comprehensive engineering design. The enclosure dimensions measure 484 mm x 384 mm x 63 mm, allowing flush mounting in standard control cabinets. It supports a power input of 24 V DC and a maximum power consumption of 70 W, ensuring compatibility with common programmable logic controllers and power distribution modules. The display module integrates 1 x USB port, 1 x Ethernet port, and 2 x RS232/RS485 serial interfaces for connectivity to both modern fieldbus networks and legacy serial devices. The panel operates reliably in ambient conditions from 0°C to +55°C and can be stored in temperatures ranging from -20°C to +60°C. The protective panel mounting design secures the unit within control enclosures while concealing rear wiring.
Operational features demonstrate the panel’s performance in demanding applications. The resistive touchscreen offers accurate single-touch response, even when used with work gloves, while the TFT LCD delivers vibrant color rendering and wide viewing angles. With a maximum ambient humidity tolerance of industrial levels and an IP65-rated front bezel, operators experience minimal display interference from moisture or dust. The low-profile depth of 63 mm reduces enclosure intrusion and simplifies retrofits. A robust weight distribution of Approx. 8.5 kg ensures stable operation without susceptibility to vibration or displacement.
System integration is streamlined via the built-in Ethernet interface, enabling high-speed data exchange with SCADA systems, PLCs, or edge controllers. The panel’s compatibility with standard 24 V DC control circuits simplifies wiring schemes and reduces component inventory. Ideal for process control, packaging machines, material handling systems, and factory automation lines, the 5AP930.1906-K03 brings a dependable operator interface solution to diverse industrial applications.
