5D2210.01/J0
The 5D2210.01/J0 from B & R Automation is a versatile member of the 5D2 Control Display Panels series, engineered for industrial automation environments. This rugged display unit features a Thin Film Transistor (TFT) color display with a diagonal display length of 10.4 Inches, delivering crisp visuals for operator interfaces. Equipped with a compact fluorescent lamp background light offering 200 cd/m2 brightness, the unit supports high readability in diverse lighting conditions. With a native Video Graphics Array (VGA) resolution of 640 x 480 pixels and the ability to render over 262,144 colors, it provides detailed graphical feedback for control processes. The front panel meets an IP65 protection rating, ensuring resistance to dust and water splashes, while the rear housing is rated IP20 for secure installation.
Technical capabilities of this display unit are comprehensive and well-suited for demanding industrial applications. The compact fluorescent lamps behind the screen offer a lifespan of 25,000 hours, reducing maintenance cycles and downtime. The integrated analog resistive touch technology delivers precise input recognition without the need for pressure-sensitive keys, enhancing operational accuracy. Housed in a black anodized aluminum frame with a polyester decor foil, the unit balances durability with corrosion resistance. At a total weight of 2 kg and dimensions of 236 mm length by 310 mm width, the 5D2210.01/J0 maintains a compact footprint while meeting ruggedness requirements.
Operational features of the 5D2210.01/J0 emphasize reliability and ease of use in industrial environments. The IP65 front panel protection prevents ingress from dust and water directed at any angle, ensuring continuous operation in washdown or washout scenarios. The background illumination brightness of 200 cd/m2 and a display capable of over 262,144 colors guarantee clear visibility of critical data, even under variable lighting. Maintenance is simplified by the long-life 25,000-hour background light and the robust anodized aluminum frame, which withstands corrosive industrial atmospheres. The intuitive resistive touch interface improves operator ergonomics and reduces training time, leading to higher productivity and fewer input errors.
Designed for seamless integration into B&R Automation control systems, the 5D2210.01/J0 pairs effortlessly with IPC2000 and IPC2001 controllers via standard communication interfaces. Its compact form factor and IP20 rear protection rating facilitate simple panel mounting in cabinets or control racks. Ideal for use in packaging lines, manufacturing cells, robotics workstations, and process control applications, this display unit enhances system diagnostics and real-time monitoring. Whether deployed in food and beverage, automotive assembly, or pharmaceutical production, the 5D2210.01/J0 delivers consistent performance and durable reliability in challenging industrial settings.
