5D5200.04

The B & R Automation 5D5200.04 digital input module in the 5D5 Provit Interface Panels series delivers precise and reliable signal acquisition for industrial automation systems. Featuring 16 channels and a typical input current of 3 mA per channel, this module ensures consistent detection of field signals. Its 24V DC input voltage compatibility and Sourcing (PNP) input type make it suitable for a wide range of analog and digital sensors. The robust design incorporates 500V AC (channel to backplane) isolation voltage to protect against electrical noise and transient spikes. With a compact footprint of 100 x 60 x 120 mm (H x W x D) and DIN-rail mounting, the 5D5200.04 integrates seamlessly into control cabinets.

The technical specifications of the 5D5200.04 reflect its engineered precision. It supports Logic 0 Voltage of 0 to 5V DC and Logic 1 Voltage of 15 to 30V DC, ensuring clear discrimination between off and on states. The module’s response time of ≤ 2 ms enables rapid state detection, while the operating temperature range of 0 to +55°C and storage temperature of –25 to +85°C guarantee stability across environmental extremes. Internal electronics are safeguarded by its 500V AC isolation voltage, minimizing cross-channel interference. Connections are handled via a removable spring clamp connector type, simplifying field wiring and maintenance.

Operationally, the 5D5200.04 delivers consistent performance under demanding conditions. Its 16 channels operate independently, allowing simultaneous sampling of multiple inputs with minimal latency. The module’s low typical 3 mA input current per channel reduces power consumption and heat generation in dense cabinet installations. Its Sourcing (PNP) configuration provides universal compatibility with standard industrial sensors. The compact 100 x 60 x 120 mm housing and DIN-rail mounting ensure ease of installation and serviceability.

System integration of the B & R Automation 5D5200.04 is optimized for modern PLC and PAC controllers. The module adheres to industrial communication standards and interfaces directly with B&R Automation backplanes. Its comprehensive electrical isolation and strict logic voltage thresholds enhance signal integrity in complex machine architectures. Ideal for process control, assembly lines, packaging machinery, and other automation applications, the 5D5200.04 delivers reliable digital input monitoring where precision and uptime are critical.
