5D5601.11
The 5D5601.11 unit from B & R Automation is a distinguished member of the 5D5 Provit Interface Panels series designed for robust industrial automation. This Interface Panel features a 12.1-inch TFT color display with an 800 x 600 resolution supporting 262,144 colors and a brightness of 300 cd/m², ensuring clear visibility in variable lighting conditions. Powered by a 24 V DC supply, the panel is engineered to interface seamlessly with IPC5000 and IPC5600 controllers, enabling real-time monitoring and control in high-demand production environments.
Detailing its rugged construction, the 5D5601.11 houses a polyester décor foil-sealed front protected to IP65 and NEMA 250 Type 4X standards, while the rear offers IP20 ingress protection. The anodized aluminum frame and flat gasket seal guard against dust and moisture, and the Accu-Touch analog resistive touchscreen delivers precise input. Operating between 0°C and 50°C (storage −20°C to +60°C), it accommodates relative humidity from 5% to 85% without condensation. The unit includes 25 function keys, one system key, and an AT keyboard port, all secured behind the sealed cover to prevent unauthorized access.
Beyond its core display and control capabilities, this panel offers flexible installation with various remote cable lengths and RS232 extension cables for touch functionality. The backlight lifespan of 50,000 hours at 25°C enhances long-term reliability, while the slim dimensions (482 mm × 310 mm × 31 mm) and 4.8 kg weight streamline integration into control cabinets. Certified to CE, cULus and TUV approvals, the 5D5601.11 Interface Panel brings exceptional durability, precise interaction, and compliance assurance, making it an ideal choice for critical industrial applications requiring dependable performance and extended service life.
