5D9212.02
The B & R Automation 5D9212.02 display unit is part of the 5D2 Control Display Panels series, engineered specifically for seamless integration with the IPC5000 industrial controller. It features a high-contrast Thin Film Transistor display type and a Compact Fluorescent Light background lighting system, providing uniform illumination and vibrant imagery. Capable of rendering 16,000,000 colors, this unit ensures precise color fidelity for intricate graphical interfaces. With its primary function as a rugged, high-performance human–machine interface, it excels in monitoring and controlling complex industrial processes.
Incorporating a generous 20.1 inches Display Diagonal and an Extended Graphic Array resolution of 1024 x 768 pixels, the 5D9212.02 delivers sharp, detailed visuals for advanced automation tasks. The front panel meets the IP65 protection standard, resisting dust ingress and water splashes, while the back side is rated IP20. The screen is protected by a Non Reflective Glass Filter that minimizes glare in bright environments. Interactive operation is enabled by Analog Resistive Touch Technology, offering accurate and responsive input without physical keys. The frame is crafted from anodized aluminum, combining lightweight durability with high corrosion resistance, and the complete assembly weighs 10.2KG.
Designed for durability and efficiency, this display unit boasts a background light lifespan of approximately 50,000 hours, after which intensity remains at 50% of its original output. A flat gasket seals the display front, and the polyester decor foil enhances resistance to wear and chemicals. Packaged in a recyclable cardboard container, it maintains optimal ambient and humidity conditions during transport. Compliance with industrial IP ratings and robust construction underline its reliability in demanding applications. By integrating this unit, operators benefit from extended service life, reduced maintenance, and enhanced process visibility in automated production and processing environments.
