5PC800.B945-01

The B & R Automation 5PC800.B945-01 high-performance industrial controller from the 5PC Industrial Automation Units series combines a dual-core processing architecture with versatile I/O integration to meet the stringent demands of automated manufacturing systems. At its heart lies an Intel Core2 Duo L7400 processor, operating at a clock frequency of 1.5 GHz and built on a 65 nm process node to deliver efficient computation with minimal thermal footprint. The controller supports a DDR2 memory type with a maximum memory capacity of 3 GB across 2x SO-DIMM sockets, ensuring rapid data access for real-time control algorithms. Integrated graphics are provided by the Intel Graphics Media Accelerator 950, offering up to 224 MB of graphics memory and supporting DVI resolutions up to 1920 x 1080 and RGB output at 2048 x 1536 @ 75 Hz. An embedded Realtek RTL8111C Ethernet Controller and optional interface modules enable seamless connectivity in Ethernet-based industrial networks.

Technical specifications reflect a robust design optimized for industrial environments. The system employs an Intel 945GME chipset and a front side bus speed of 667 MHz to coordinate data flow between CPU, memory, and peripherals. Cache hierarchy comprises a 32 KB L1 cache and 4 MB L2 cache to accelerate instruction execution and minimize latency. Mass storage can be configured via 2x SATA ports and a legacy IDE connector, while ACPI 2.0 power management with S3 suspend-to-RAM support ensures low-power operation during idle or maintenance periods. The embedded BIOS is implemented as an AMI Basic Input/Output System (BIOS) with real-time clock capabilities for accurate time-stamping of control events.

Operational features emphasize reliability and continuous performance under harsh conditions. The controller's thermal design leverages low-power CPU architecture to maintain stable operation without active cooling in typical ambient ranges. The DDR2 memory interface with ECC support options provides data integrity during high-frequency read/write cycles, and the motherboard's soldered LAN controller ensures sustained network throughput. Vibrations and electrical noise common in industrial environments are mitigated through onboard filtering, conforming to relevant EMC standards. Maintenance requirements are minimized, with no scheduled part replacements and remote diagnostics enabled via the Ethernet interface.

System integration is simplified by the controller's compact board-level form factor, which mounts directly onto standard DIN rails or custom mounting plates. It interfaces natively with B & R Automation's APC 820 system modules and Beckhoff-compatible I/O expansion units, supporting hot-swappable optional interface cards for serial, fieldbus, or CAN protocols. The combination of 5PC800.B945-01 reliability and flexible expansion makes this controller ideal for machine tool control, packaging systems, material handling equipment, and other high-availability industrial automation applications.
