S image of 601001705

601001705

by Kollmorgen
$8,771.00 - $8,771.00
$8,771.00
$8,771.00 - $8,771.00
$8,771.00

In Stock, Ships Fast

The product in focus is a Kollmorgen-manufactured graphic operator terminal, the 601001705 (AKI-CDT-MOD-10T-000). It is designed with a polyester-on-glass touch screen and employs a TFT-LCD display. Weighing 2.1 kg, this terminal boasts a vibrant color display of 64K colors with an 800 x 600-pixel resolution. It also features a backlight with a lifespan of 50,000 hours when operated at 25o C. The 601001705 (AKI-CDT-MOD-10T-000) terminal is quipped with type I & II compact flash slots, a type-A USB 1.1 slot, and a shielded RJ-45 Ethernet interface. The 601001705 (AKI-CDT-MOD-10T-000) terminal has a depth of 58mm, extending to 158mm inclusive of clearance, and features a front panel measuring 302mm x 228mm x 6mm. The product's frame and enclosure are made of powder-coated aluminum, giving it resistance to various substances like edible oil, fuel oil, acetic acid (10%), and seawater. The touchscreen is secured by Autotex F157/F07, offering additional protection. With IP66 and IP20 protection for the front and rear panel respectively, the 601001705 (AKI-CDT-MOD-10T-000) has a 24V DC power supply adhering to IEC 61558-2-4 and IEC 60950 standards. It works in temperatures ranging from 0 – 50o C as per the installation (vertical or horizontal) with a storage temperature range of -20o C to 70o C. It is vital that servicing and repairs be handled by qualified individuals.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Display Colours

64K

Operating Temperature

0 – 50o C (vertical installation), 0 – 40o C (horizontal installation)

Front Panel Dimension

302 mm x 228 mm x 6 mm

Manufacturer

Kollmorgen

Backlight Lifespan

50000 hours at 25o C
