S image of 601001706

601001706

by Kollmorgen
$15,762.50 - $15,762.50
$15,762.50
$15,762.50 - $15,762.50
$15,762.50

In Stock, Ships Fast

Product 601001706 (AKI-CDT-MOD-15T-000) is a graphic operator terminal from renowned manufacturer Kollmorgen. Lightweight at 2.1 kg, it features a polyester-on-glass touchscreen display employing the TFT-LCD variant with 64K colours and a resolution of 800 x 600 pixels. It boasts a display backlight with a lifetime of 50000 hours at 25o C. The terminal supports Type I and II compact flash slots, a Type-A USB 1.1 slot, and a shielded RJ-45 Ethernet interface. The 601001706 (AKI-CDT-MOD-15T-000) has a mounting depth of 58 mm (158 mm including clearance). Its front panel dimensions are 302 mm x 228 mm x 6 mm, with a durable casing and frame made of powder-coated aluminium that is resistant to exposure to various substances. The touch screen is protected by Autotex F157/F07 for added safety. The front and rear panel are respectively IP 66 and IP 20 protected. Its operating power is 24 volts DC, and operates efficiently between 0 – 50o C for a vertical installation, and 0 – 40o C when installed horizontally. The unit should be stored within a temperature range of -20o C to 70o C. Repairs, servicing and maintenance should only be carried out by qualified personnel.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Maintenance Protocol

Servicing by Qualified Personnel Only

Product Type

Graphic Operator Terminal

Frame Material

Powder-coated Aluminium

Manufacturer

Kollmorgen

Backlight Lifetime

50000 hours at 25o C
