602221730
by Kollmorgen
The 602221730 (AKI-CDT-MOD-06T-000) is a fine specimen of Kollmorgen's range of products- a 5.7-inch touchscreen HMI terminal that displays an appealing design with its aluminum frame and powder-coated steel-grey appearance. Manufactured to withstand rigid conditions, the 602221730 (AKI-CDT-MOD-06T-000) with its IP 66 rated front enclosure, assures damage-free performance, even under high-pressure water jets. Equipped with a user-friendly and intuitive software tool, the 602221730 (AKI-CDT-MOD-06T-000) showcases a vivid TFT-LCD display of 320 x 240 pixels resolution supporting 64K colours, enclosed by a polyester-on-glass touch screen and an Autotex F157/F207 overlay.
Optimized to run on an Intel Xscale (RISC CPU) processor of 416 MHz speed, the 602221730 (AKI-CDT-MOD-06T-000) is equipped with a working memory of 64 MB and a real-time clock. Its 2.0 AT, 5 mm x 20 mm internal fuse, and 24 Volts DC power supply adds to its durability and functioning. With operating temperatures of 0 – 50°C and 0 – 40°C respectively for vertical and horizontal installations, storage temperature tolerance of -20 – 70°C, and an optimized operating humidity of 5 – 85%, it guarantees top performance in varied conditions. The unit offers large viewing angles, has a built-in RJ45-shielded Ethernet communication port, a 500-mA type A USB host, and weighs 900 grams with cut-out dimensions of 180 mm x 130 mm.
