The Sanyo Denki 68AA050VXE05 is a NEMA 23 frame stepper motor in the ABS Super Servo Amplifiers series, offering 0.5 Nm holding torque, 1.8° step angle, 2.8 A per phase and 1.2 Ω resistance. It runs on 100–120 V AC with natural convection cooling, features a 6.35 mm shaft and operates from −20°C to +50°C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Control Interface
Pulse/Direction and Analog Input
Cooling Method
Natural Convection
Frame Size
NEMA 23
Holding Torque
0.5 Nm
Inductance/phase
3.5 mH
Input Voltage Range
100–120 V AC
Length (body)
56 mm
Number Of Leads
4
Operating Temperature
-20°C to +50°C
Phase Resistance
1.2 Ω
Rated Current/phase
2.8 A
Shaft Diameter
6.35 mm
Shaft Length
20 mm
Step Angle
1.8°
Type
Stepper Motor
