The 7225AC from Copley Controls offers a peak power of 20 A @110V and a continuous power rating of 10 A @130V. Part of the DC Servo Amplifiers, it handles mains voltage of 32~132VAC, a mains current of 16 A, and operates with a PWM frequency of 25kHz.
It employs a differential reference input and features a minimum load inductance of 400 uH with an external mains fuse rating of 20 A/125V. The unit measures 7.50 x 6.94 x 2.72 in and weighs 3.71 lbs.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Enable Input Active Polarity
OFF (default): Gnd enables amplifier, open or +5V inhibits
External Mains Fuse Rating
20 A/125V
Inrush Current On Startup
19 A
Mains Current
16 A
On-resistance
0.2 ohms
Operating Temperature Range
0 degrees to 70 degrees C baseplate temperature
Size
7.50 x 6.94 x 2.72 in. (190 x 174 x 69 mm) without optional heatsink
