The 7229DC is a DC servo amplifier from Copley Controls’s DC Servo Amplifiers series. It features an on-resistance of 0.2 ohms, operates on 32~132VAC, 47~63Hz, and delivers 20 A @ 110V peak and 10 A @ 130V continuous. With a 25 kHz PWM frequency and a small-signal -3 dB bandwidth at 3 kHz, it ensures precise, high-speed motion control.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Amplifier Dissipation - Minimum Power
17W
Bandwidth
Small signal -3dB @ 3kHz
Connector Type For Power And Motor
Barrier-block, Screw-terminal connections
Load Inductance - Minimum
400 uH
Mains Voltage
32~132VAC, 47~63Hz
On-resistance
0.2 ohms
Operating Temperature Range
0 degrees to 70 degrees C baseplate temperature
Output Power - Continuous
10 A @ 130V
Output Power - Peak
20 A @ 110V
Pwm Frequency
25kHz maximum
Thermal Resistance - No Heatsink Or Fan
0.92 deg. C/W
Thermal Resistance - With Heatsink And Fan
0.23 deg. C/W
Weight Without Heatsink
3.71 lbs. (1.69 kg)
