7CM211.7
The 7CM211.7 module, manufactured by B&R Automation, is a high-performance combination module tailored for modern industrial automation systems. It features 8 inputs and 8 transistor outputs, supporting versatile applications. Operating at 24 VDC and consuming a maximum of 1.5 W, it uses a successive approximation conversion method, achieving a 4 ms conversion time for cyclic channel processing. The module can withstand continuous overloads of +/-15 V or +/-50 mA using sink wiring. It supports 3 one-channel or 2 two-channel counters, 2 encoders, and handles input frequencies up to 20 KHz. Equipped with 8 green LEDs, it provides clear status displays. Each output supports up to 0.5 A with features like short-circuit protection, comparator function, and a 47 V braking voltage for inductive loads. The module includes asymmetric analog inputs +/-10 V / 0-20 mA at 12-bit resolution. It requires a separate TB718 terminal block for integration, ensuring robust performance in complex automation tasks.
