800-1536
The 800-1536 device from Copley Controls in the Accelnet CanOPEN Modules series is a high-performance digital servo drive engineered for precise control and reliable operation. It supports both CANopen and RS232 serial communication protocols and accepts a DC input ranging from 20 to 90 V, achieving a peak output current of 18 A and a continuous output current of 6 A. The drive also provides connectivity with up to 3 digital outputs and 12 digital inputs, along with versatile feedback options for motor control. Key internal components include capacitors of 0.01 uF, 1 nF, 2.2 uF, and 4.7 uF, a diode (1N5819), resistors (50 Ohm, 84.5K Ohm, among others), a transistor (RJK0305DPB), and precise control signals such as a PULSE pattern and a 24V reference, ensuring robust performance in demanding applications.
