8F1CP0X38.11110-0
The 8F1CP0X38.11110-0 ball screw support unit from B & R Automation is an integral component of the ACOPOStrak Systems family, engineered to provide robust support for precision motion assemblies. This Type: Ball Screw Support Unit utilizes a high-strength Body Material: Steel construction paired with a Flange Shape: Square Flange for straightforward mounting and enhanced rigidity. It accommodates a Shaft Diameter: 10 mm and maintains an overall footprint of Overall Width: 38 mm, Overall Height: 28 mm, and Overall Length: 38 mm to fit compact machine designs. Despite its durable design, the unit weighs only Weight: 0.6 kg, offering an excellent power-to-weight ratio that reduces inertial loads on drive systems. Its square flange configuration streamlines installation in modular automation frameworks, ensuring consistent alignment under heavy-duty conditions.
Performance is optimized through the incorporation of an Angular Contact Ball Bearing with Bearing Preload: Light Preload, enabling combined axial and radial load handling with high accuracy. The support unit is rated for a Max Allowable Axial Load: 7.35 kN, making it suitable for demanding thrust applications in industrial environments. Precision mounting is facilitated by Mounting Hole Diameter: M5 locations spaced at a Mounting Hole Pitch: 30 mm, ensuring repeatable assembly and simple integration with existing hardware. The compact design minimizes backlash and vibration, while the steel housing provides excellent resistance to mechanical wear and deformation. Together, these technical features ensure the support unit delivers smooth, low-friction operation and maintains tight positional tolerances throughout extended duty cycles.
Built for reliability and seamless integration, this support unit delivers consistent performance in a variety of industrial automation applications. Its robust steel body and precision bearing system ensure long-term durability, even in high-vibration or high-acceleration environments. The compact square flange and standardized mounting pattern simplify retrofitting into ACOPOStrak tracks or custom machine assemblies, reducing engineering lead times and assembly complexity. Engineers will find this unit particularly valuable in packaging machinery, assembly lines, and material handling systems where precise linear motion and load capacity are critical. By combining proven bearing technology with a lightweight, modular design, the 8F1CP0X38.11110-0 support unit underpins reliable, high-throughput automation solutions.
