8F1GC.AD66.BA000-1
The B & R Automation 8F1GC.AD66.BA000-1 guide module is a high-precision component in the ACOPOStrak Systems portfolio designed for robust industrial automation. This module features a DPDT (Double Pole Double Throw) contact configuration for flexible switching and supports a contact rating of 8 A at 250 VAC / 30 VDC to drive a range of loads. The device is powered by a 24 V DC coil voltage and withstands a dielectric strength of 2000 VAC for 1 min, ensuring reliable insulation under high-voltage stress. Its compact enclosure is optimized for DIN rail mounting, streamlining integration into complex control cabinets.
The technical specifications of the 8F1GC.AD66.BA000-1 underline its durability and precision. It delivers a mechanical life of 10,000,000 operations and an electrical life of 100,000 operations, ensuring longevity in high-cycle applications. The module’s insulation resistance of 1000 MΩ at 500 VDC minimizes leakage current, while its enclosure material of polycarbonate provides impact resistance and flame retardancy. The device measures 92 mm x 55 mm x 64 mm and weighs 180 g, offering a compact footprint without sacrificing performance.
Operationally, the guide module performs reliably across a -20°C to +60°C operating temperature range and can be installed quickly via its DIN rail mount interface. The precise DPDT contacts enable seamless transition of control signals for bi-directional actuation, reducing transition time and contact wear. The module’s high dielectric strength and robust insulation support safe operation in environments with electrical noise and transient surges. Polycarbonate housing coupled with sealed internals protects against dust and incidental moisture, maintaining performance in industrial settings.
Integration of the 8F1GC.AD66.BA000-1 into automated systems is straightforward, leveraging standard rail mounting and industry-standard coil voltage levels. It is ideal for conveyor control, pick-and-place systems, and automated assembly lines within discrete manufacturing facilities. Compatibility with B & R Automation’s ACOPOStrak controller architecture ensures synchronized motion and precise timing. The module’s proven reliability and ease of replacement make it a preferred choice for engineers seeking durable, low-maintenance switching elements.
