8I64T400300.00X-1
Original price
$2,970.00
-
Original price
$2,970.00
Original price
$2,970.00
$2,970.00
-
$2,970.00
Current price
$2,970.00
The B&R 8I64T400300.00X-1 inverter module is engineered for robust performance in industrial applications. It supports motor power of 3 kW and operates efficiently within a mains voltage range of 3x 380 VAC -15% to 500 VAC +10%, and a frequency range of 50 to 60 Hz ±5%. Delivering an apparent power of 7.1 kVA at 500 VAC, it offers effective energy management, handling up to 5 kA of short-circuit current. Without the optional mains choke, it supports a maximum mains current of 10.9 A at 380 VAC and 8.3 A at 500 VAC. These values decrease to 6.5 A at 380 VAC and 5.2 A at 500 VAC with the choke, enhancing performance. The module efficiently manages thermal output with 125 W power dissipation, and its included EMC filter ensures compliance with electromagnetic standards. Compact and durable, it operates up to 60°C and integrates seamlessly into diverse industrial setups.
30 Day Warranty
Technical Specifications
