8JSA22.R0080D200-0
The 8JSA22.R0080D200-0 synchronous motor from B & R Automation is a high-performance solution in the 8JS Synchronous Motors series designed for compact, accurate motion control in industrial automation systems. This motor delivers a nominal power of 528 W and a nominal speed of 8000 RPM, producing a nominal torque of 0.63 Nm for consistent load handling. Featuring a stator resistance (R2ph) of 19.98 Ω and a voltage constant of 39 V/1000 rpm, it ensures precise voltage-to-speed conversion under dynamic conditions. The motor’s stator inductance (L2ph) of 35.5 mH and electrical time constant of 1.8 ms support rapid current response for demanding cycles. Packaged in a compact 2512 package with ±0.5% tolerance, the device maintains tight dimensional accuracy for seamless integration. Additionally, the motor’s thermal time constant of 9 min enables high-speed operation with effective heat dissipation.
Performance characteristics of the 8JSA22.R0080D200-0 emphasize both dynamic response and electrical efficiency. The low moment of inertia (0.16 kg·cm²) allows swift acceleration and deceleration, optimizing cycle times in pick-and-place or indexing applications. With a self-cooling design and flange mounting style, the motor minimizes external cooling requirements while ensuring secure installation. Its Encoder System: Resolver with 10 angular minutes accuracy provides reliable position feedback under vibration. The Angled (swivel connector) connection direction eases cable routing in tight machine layouts. A standard holding brake option maintains load position during power interruptions, adding an extra layer of safety. Conforming to ROHS compliant standards, this motor meets modern environmental directives.
Reliability and system integration are hallmarks of the 8JSA22.R0080D200-0 design. The robust thermal profile and self-cooling mechanism prolong service life under continuous operation. Its compact motor length (2) and motor size (2) support space-constrained drives and gantry systems. The combination of resolver feedback, stable voltage constant, and predictable electrical time constant ensures smooth motion profiles and simplifies tuning procedures. Ideal for industrial automation, robotics, semiconductor handling, and high-speed tooling, this motor delivers consistent performance in demanding environments. Integration with B & R Automation controls enables advanced motion algorithms and seamless communication within automated production lines.
