manufacturer image of 8LSA55.S0030D900-3

8LSA55.S0030D900-3

by B & R Automation
Request a quote
B & R Automation is a world renowned supplier of innovative motion control products and the 8LS three-phase synchronous motors exemplify their commitment to high performance and compact design. Specifically, the 8LSA55.S0030D900-3 model is a permanent-magnet motor with electronic communication optimizing torque rippling. Its design includes a self-cooling mechanism supported by a mounting flange that also functions as a cooling surface and an attachment point. The motor features the EnDat 2.2 optical encoder with single-turn configuration for optimal functional safety and precise indirect position recording. With a nominal speed of 3,000 rpm, integrated angled connectors, separate power and encoder cable connections, a standard holding brake, and form A DIN 3760 oil seal for IP 65 Ingress Protection Rating, this motor is ideal for the plastics, metalworking, beverage and food industries.
30 Day Warranty
Technical Specifications
  • Manufacturer: B & R Automation
  • Product Type: Three-phase Synchronous Motor
  • Model: 8LSA55.S0030D900-3
  • Motor Type: Permanent-Magnet
  • Electronic Commutation: Yes
  • Cooling Type: Self-Cooling
  • Built-in Encoder: Yes
  • Encoder Type: EnDat 2.2 optical single-turn
  • Nominal Speed: 3,000 revolutions per minute
  • Connector Type: Angled
  • Cable Connection: Separate for encoder and power
  • Holding Brake: Standard
  • Oil Seal: DIN 3760 form A
  • Ingress Protection Rating: IP 65
  • Control Compatibility: B&R Drive System with 8LS motor.
