8LVB13.B1015F000-0
The B & R Automation 8LVB13.B1015F000-0 gear motor delivers precision actuation within the 8LVB Gear Motors series, featuring a robust Double Acting design optimized for industrial automation. With a Bore Size of 15 mm and Rubber cushion damping, this unit ensures smooth, repeatable motion control in high‐duty applications. Constructed with an Aluminum body material, the gear motor integrates a Male thread piston rod and offers a compact Basic mounting footprint. Operating over a Pressure Range of 0.1 to 0.7 MPa, it provides reliable performance in demanding environments. The cylinder’s Magnet For Auto Switch capability supports external sensing for position feedback and system diagnostics.
The motor’s mechanical interface features a Stroke Length of 15 mm and a Maximum Allowable Stroke of 150 mm, accommodating diverse motion profiles. The Port Size of M5 simplifies pneumatic connections while the Operating Temperature Range from -10°C to +70°C ensures durability under varying thermal loads. A Thermal Time Constant of 15 minutes maintains winding temperature stability, corresponding to its Insulation Class F rating for up to 155°C. The piston assembly is guided by precision seals and includes a Mounting Type IM3001/IM3011/IM3031 option set to suit multiple installation configurations.
In dynamic operation, the unit reaches a Maximum Speed of 6600 r/min and a nominal continuous speed of 1500 r/min at 0.8 A current draw. It delivers a Nominal Torque of 0.34 Nm and a Stall Torque capacity of 0.36 Nm, with a Stall Overload Current of 0.9 A. The integrated gearbox provides tailored output ratios, while a Moment of Inertia of 0.03 kgcm² supports rapid acceleration and deceleration. The unit offers a 5 million cycle holding brake rated at 0.35 Nm and an IP54 Protection Rating to guard against dust and water ingress. Precise feedback is provided by an EnDat 2.2 Multiturn Encoder, supplemented by a stator resistance of 17.4 Ω at 20°C.
System integration is streamlined via compatibility with a range of servo drives including ACOPOSmicro, 80VD100Px.xxxx-01, and ACOPOS 8Vxxxx.xx... 1010.50. Electrical connections are secured through a double angular built-in connector, recommending a Cable Cross Section of 0.75 mm². The unit’s Back EMF Constant of 25.13 V/1000 r/min enables precise voltage control in closed-loop drives. Mounting options IM3001, IM3011, and IM3031 facilitate integration into compact assemblies, making the 8LVB13.B1015F000-0 ideal for precision packaging, pick-and-place systems, and robotic end-effectors in industrial automation.
