The Copley Controls ACK-055-10 is a compact digital servo drive from the Accelnet CanOPEN Modules series. Operating on 20-55 Vdc, it supports Indexer and Camming control modes, offers 10 digital inputs, delivers 5 Adc continuous current with a 2.5 kHz current loop bandwidth. Measuring 63.5×40.6×21.1 mm, it features an auto-adjustable 2.8 Vrms reference voltage and supports up to 10,000 RPM.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Agency Standards Conformance
Complies with EC 2014/35/EU & 2014/30/EU
Command Interfaces
Stepper, ±10V pos/vel/torque, PWM vel/torque, encoder
Communication Interfaces
CANopen, DeviceNet, RS232, ASCII, discrete I/O
Continuous Current
5 Adc
Control Loop Update Rate
3 kHz
Control Modes
Indexer; PTP/PVT; Camming; Gearing; P/V/T
Current Loop Bandwidth
2.5 kHz (typical)
Digital Inputs
10 channels
Digital Outputs
3 channels
Dimensions
63.5 x 40.6 x 21.1 mm
Feedback
Quadrature encoder, Hall sensors; optional resolver
Operating Temperature
0 to +45 °C
Peak Current
10 Adc
PWM Ripple Frequency
30 kHz
Voltage Range
20-55 Vdc
