ACM-090-60
The Copley Controls ACM-090-60 drive is a compact, high-performance member of the Accelnet CanOPEN Modules series designed for precise 3-phase motor control in industrial automation. It operates over a broad voltage range of 20 - 90 Vdc and delivers a continuous current of 30 Adc with peaks up to 60 Adc, making it suitable for both steady-state and transient load conditions. The module integrates a MOSFET 3-phase inverter output stage to drive brushless and DC motors efficiently, while its compact footprint of 102.7 mm x 66.5 mm x 24.9 mm simplifies mounting in densely packed panels. Conforming to EN 55011, EN 61000-6-1, EN 60204-1, UL 508C, RoHS, it meets stringent electromagnetic compatibility and safety requirements for global deployment. These capabilities establish the ACM-090-60 as a reliable solution for robotics, packaging, CNC, and material handling systems.
Technical specifications for the ACM-090-60 detail its robust connectivity and protection features. It supports both CANopen and RS-232 communication ports for flexible network integration and diagnostics. The drive provides 10 inputs, 2 outputs for digital I/O and incorporates built-in protection against overvoltage, undervoltage, over temperature, and short circuits. Its storage temperature range of -40 to +85 degrees C and operating range of 0 to +45 degrees C ensure reliable performance under varied environmental conditions. Weighing 0.16 kg, this module combines low mass with high power density to minimize strain on mounting hardware.
Operational performance of the ACM-090-60 emphasizes thermal stability and dynamic response. The integrated thermal protection continuously monitors junction temperatures to prevent overheating during extended duty cycles. The high-efficiency MOSFET power stage and optimized PWM switching deliver low electrical noise and rapid current regulation for precise torque control. Digital diagnostics accessible via CANopen allow real-time monitoring of current, voltage, and temperature parameters, facilitating preventive maintenance. The drive’s fast current loop and configurable digital inputs support advanced motion profiles and rapid start/stop sequences.
System integration is streamlined through plug-and-play compatibility with industry-standard CANopen networks and Copley Controls’ configuration tools. The module’s compact dimensions and standardized mounting options enable simple retrofitting into existing control cabinets. Its feature set targets applications in robotic arms, conveyor systems, packaging machines, and CNC devices where space constraints and high reliability are critical. The ACM-090-60 ensures consistent performance in demanding industrial environments while reducing development time and maintenance costs.
