ACS4815-525F
by Kollmorgen
The Kollmorgen ACS4815-525F drive unit from the AC SuperDrive Motion Units series is engineered for demanding industrial automation tasks. Designed to operate on a 48 V DC input and deliver up to 175 Arms (2 min) of driving current, this device supports both 3-phase induction motors with squirrel-cage rotors and permanent-magnet synchronous motors. With an IP65 protected housing, the ACS4815-525F resists dust and water ingress, ensuring reliable performance in harsh environments. Primary functions include precision speed and torque control for conveyor systems, robotic actuation and material-handling applications.
Incorporating a host of advanced technical features, the ACS4815-525F uses the CAN communication protocol for seamless integration with modern control networks. It offers selectable switching frequencies of 8, 12 or 16 kHz (rated at 8 kHz) to optimize efficiency and noise performance. The unit’s control mode can be switched between speed and torque regulation to suit dynamic load conditions. Power connections utilize M6 bolts and an AMP SEAL 23-pin connector to guarantee secure electrical interfaces. With a continuous output of 3.2 kVA (1 h) and peak output of 9.6 kVA (2 min), this drive ensures robust energy delivery for high-demand motion sequences.
Built for durability, the ACS4815-525F withstands operating temperatures from –40 °C to +55 °C and storage temperatures from –40 °C to +70 °C at up to 95 % humidity. The compact unit measures 65.8 mm in height and weighs just 1.6 kg, facilitating integration into tight machine layouts. Compliance with EN 1175-1 and UL 583 standards underscores its safety and quality credentials. With a one-year warranty, IP65 protection and wide temperature tolerances, this drive unit delivers exceptional reliability and efficiency in industrial automation, reducing downtime and maintenance costs while providing precise motor control across diverse applications.
