ADF104C-B05TR1-AS06-A2N2
The ADF104C-B05TR1-AS06-A2N2 from Bosch Rexroth Indramat represents a robust solution within the ADF Main Spindle Motors series, delivering reliable performance in a compact package. This liquid-cooled asynchronous motor features a Motor Size of 104 and a Motor Length coded as C, optimizing power density without compromising footprint. Designed for precision machinery, it employs a Flange mounting scheme for secure installation and a Power Connection Direction to the Right, facilitating streamlined cable routing. With a Power Connection Type of Connector/Plug and a Power Connection Housing Position at Top, setup and maintenance are simplified in tight spaces.
Technical capabilities of the ADF104C-B05TR1-AS06-A2N2 highlight its engineered balance and endurance. The motor achieves an S DIN ISO 2373 Balance Quality, minimizing vibration at high speeds, while the Standard Bearing design ensures consistent rotational accuracy. Its Digital servo feedback system delivers precise rotor position monitoring, and the Winding Code AS affords optimized electrical performance. The Coolant Connection Type is Standard, enabling efficient liquid cooling to sustain continuous operation under heavy loads. Notably, the motor is configured Without holding brake, streamlining its mechanical assembly.
Operational features emphasize smooth integration and sustained uptime. The Plain shaft design, Without Shaft Seal Ring, reduces maintenance points and prevents wobble during rapid acceleration. A Side B Shaft End Configuration without second shaft end minimizes external complexity. The liquid cooling system maintains stable thermal conditions, enhancing continuous duty cycles with minimal thermal drift. Engineers benefit from the Power Connection Housing Position at Top for easy access during inspections, and the Flange mounting provides vibration isolation, lowering noise and extending component life.
Integration of the ADF104C-B05TR1-AS06-A2N2 into industrial environments is straightforward. Its liquid-cooled asynchronous motor architecture pairs seamlessly with standard servo drives and spindle controllers, while the Digital servo feedback supports advanced motion profiles. The compact Motor Size 104 and right-side connector orientation enable installation in confined machine tool assemblies, printing presses, and plastics molding equipment. With its combination of precise feedback, robust cooling, and streamlined mounting, this motor is ideal for applications demanding high reliability and precision.
