S image of ADP-055-18-S

ADP-055-18-S

by Copley Controls
$965.88 - $965.88
$965.88
$965.88 - $965.88
$965.88

Available, Shipping Varies

The ADP-055-18-S is a digital servo drive from Copley Controls in the Accelnet CanOPEN Modules series, offering a continuous current of 6 Adc (4.2 Arms) per phase and a peak current of 18 Adc (12.7 Arms). It features 12 digital inputs, 3 digital outputs, operates from +20 to +55 Vdc, and provides RS-232 communication at 9,600–115,200 Baud. With a 15 kHz PWM frequency and compact dimensions of 6.58 x 3.89 x 1.17 in (167 x 98.8 x 29.7 mm), it weighs 0.94 lb for flexible industrial automation applications.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Canopen

Communication protocol

Continuous Current

6 Adc (4.2 Arms) per phase

Digital Inputs

12

Digital Outputs

3

Input Voltage Range

+20 to +55 Vdc

Operating Temperature

0 to +45 degrees C

Peak Current

18 Adc (12.7 Arms)

Protection Overvoltage

+HV > HVmax

Protection Undervoltage

+HV < +20 Vdc

Pwm Frequency

15 kHz

Rs-232 Communication

9,600 to 115,200 Baud

Size

6.58 in (167 mm) X 3.89 in (98.8 mm) X 1.17 in (29.7 mm)

Storage Temperature

-40 to +85 degrees C

Weight

0.94 lb (0.43 kg)
