S image of AKI-CDT-MOD-15T-000

AKI-CDT-MOD-15T-000

by Kollmorgen
$15,762.50 - $15,762.50
$15,762.50
$15,762.50 - $15,762.50
$15,762.50

In Stock, Ships Fast

The Kollmorgen AKI-CDT-MOD-15T-000 is a specialized graphic operator terminal, weighing about 2.1 kg, with a polyester-on-glass touch screen interface. It displays images using a TFT-LCD platform accommodating 64K colors and resolution of 800 x 600 pixels. Equipped with compact flash, USB 1.1, and Ethernet slots, the unit has a specified mounting depth of 58 mm and a front panel measuring 302 x 228 x 6 mm. Sporting a durable, powder-coated aluminum casing, the terminal is resistant to various substances including edible oil, seawater, and acetic acid. The touch screen is fortified with Autotex F157/F07 for added protection. The terminal operates on a 24V DC power supply, adhering to IEC 61558-2-4 and IEC 60950 standards, and functions optimally within 0 – 50o C when vertically installed. Storage temperature ranges from -20o C to 70o C. Repair and maintenance should only be performed by qualified personnel.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Type

Graphic Operator Terminal

Weight

2.1 kg

Display Type

TFT-LCD, 64K colours, 800 x 600 pixels

Backlight Lifetime

50000 hours at 25o C

Interfaces

Type I & II Compact Flash, Type-A USB 1.1, Shielded RJ-45 Ethernet

Mounting Depth

58 mm (158 mm including clearance)

Front Panel Dimensions

302 mm x 228 mm x 6 mm

Frame Material

Powder-coated Aluminium

Touch Screen Material

Autotex F157/F07

IP Protection

Front Panel IP 66, Rear Panel IP 20

Power Supply

24 Volts DC

Operating Temperature

0 – 50o C (Vertical Installation), 0 – 40o C (Horizontal Installation)

Storage Temperature

-20o C to 70o C

Maintenance Protocol

Servicing by Qualified Personnel Only
