S image of AKI2G-CDA-MOD-05T-000

AKI2G-CDA-MOD-05T-000

by Kollmorgen
$1,307.43 - $2,461.28
$1,307.43
$1,307.43 - $2,461.28
$1,307.43

In Stock, Ships Fast

The AKI2G-CDA-MOD-05T-000, manufactured by Kollmorgen, is a 0.5 kg LCD terminal characterized by a resistive overlay touchscreen. The terminal, enveloped in grey PC+ABS plastic, exhibits a mechanical size of 170 x 107 x 49 mm with a cut-out size of 161 mm x 93 mm. This terminal encompasses a TFT-LCD display with LED backlight, offering 800 x 480 pixels and 64K colour display. The display pixel error complies with Class 1 as laid down by ISO9241-307. It embraces an ARM9 400 MHz CPU, flash memory of 256 MB, and 128 MB DDR2 RAM. The terminal hosts a USB 2.0 port, with no memory expansion mechanisms. Not suitable for use under extreme physical conditions, the terminal operates at a DC voltage of 24 V and 6W power consumption, within a temperature range of -10 - 50 degrees C. The frontal and rear sealings are IP 65 and IP 20 protected respectively.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Code

AKI2G-CDA-MOD-05T-000

Type

0.5 kg LCD terminal (5-inch)

Touch Screen Material

Resistive overlay, Polyester-on-glass, Autoflex EB

Housing Material

Grey PC+ABS plastic

Mechanical Size

170 x 107 x 49 mm

Cut-Out Size

161 mm x 93 mm

Display

TFT-LCD with LED backlight (lifetime = 20, 000 hours), 800 x 480 pixels, 64K colours

Display Pixel Error

Class 1 as per ISO9241-307

Software

Integrated interactive and easy-to-use software tool

Suitability

Not suitable for use under direct sunlight, strong magnetic fields, high explosive risks, sudden temperature changes

CPU

ARM9 400 MHz

Memory

256 MB Flash (200 MB for applications), 128 MB RAM (DDR2)

Memory Expansion

No

USB Ports

1 x USB 2.0 (500 mA)

Communication Interfaces

Serial and Ethernet

Input Voltage

DC 24 V (18 to 32 V DC)

Power Consumption

6W

Internal Fuse

DC power fuse

Operating Temperature

-10 – 50o C

Storage Temperature

-20 ≤ To C ≤ 60

Front Sealing Protection

IP 65

Back Sealing Protection

IP 20
