S image of AKI2G-CDA-MOD-07T-000

AKI2G-CDA-MOD-07T-000

by Kollmorgen
$2,548.40 - $3,547.58
$2,548.40
$2,548.40 - $3,547.58
$2,548.40
The Kollmorgen AKI2G-CDA-MOD-07T-000 is a 7-inch HMI graphical display, encased in a gray plastic (PC + ABS) housing and weighs 0.7kg. With dimensions of 196 x 146 x 52mm and a cut-out size of 186 x 136 mm, it features a resistive touch type interface. Its TFT-LCD display, with a resolution of 800 x 480 pixels, is supported by an LED backlight offering 400cd/m2 brightness and a lifespan of 20,000 hours. It uses an ARM9 400 MHz processor, a 128 MB RAM, and a built-in 256 MB storage, and supports USB interface with 1 x USB 2.0 offering 500mA output. Ideal operating temperature is -10o C to +50o C, and storage temperature is -20o C to +60o C. It complies with IP 65 standards for front sealing and IP 20 for rear. Its shock resistance and vibration endurance meet IEC standards. The device operates on +24 V DC voltage with a power consumption of 9.6 W.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Code

AKI2G-CDA-MOD-07T-000

Display Size

7 inches

Type

HMI Graphical Display

Mechanical Size

196 x 146 x 52mm

Housing Material

Plastic (PC + ABS)

Weight

0.7kg

Cut-Out Size

186 x 136 mm

Touch Type

Resistive

Display Type

TFT-LCD

Resolution

800 x 480 pixels

Backlight

LED with 20000 hours lifetime

Brightness

400cd/m2

Dimming

Industrial Dimming Mode

Display Pixel Error

Class 1 (ISO9241-307)

Processor

ARM9 400 MHz

RAM

128 MB

Flash Size

256 MB

Ethernet Port

1 x 10/100 Base-T (shielded RJ45)

Expansion Port

None

SD Card

None

USB

1 x USB 2.0 with 500mA output

Operating Temperature

-10o C to +50o C

Storage Temperature

-20o C to +60o C

Front Sealing

IP 65

Back Sealing

IP 20

Shock

15g amplitude, 11ms duration (IEC 60068-2-27)

Vibration

1g amplitude (IEC 60068-2-6)

Input Voltage

+24 V DC (18 to 32 V DC)

Average Power Consumption

9.6 W
