S image of AKI2G-CDB-MOD-07T-000

AKI2G-CDB-MOD-07T-000

by Kollmorgen
$2,766.33 - $3,255.03
$2,766.33
$2,766.33 - $3,255.03
$2,766.33

In Stock, Ships 1 - 3 Days

The AKI2G-CDB-MOD-07T-000 is an HMI panel terminal produced by Kollmorgen, weighing 0.8kg and boasting a compact size of 204 x 143 x 50 mm. It's crafted with a powder-coated aluminium housing and features a 7” TFT-LCD resistive touch screen comprised of polyester on glass with ITO film. Offering crystal-clear display with 800 x 480 pixel resolution, the screen is backlit by a 350cd/m2 LED light with a lifespan of 20,000 hours. The device employs a Single Cortex-A9 processor with a frequency of up to 1.0 GHz and is equipped with 512MB RAM and a 2GB SSD flash memory, which provides 1.5GB of free application space. It has multiple connectivity options including 9-pin DSUB serial and ethernet ports, along with a USB Host 2.0. It operates efficiently in temperatures from -10o C to 50o C and meets both NEMA 4X/12 and IP 65 requirements, drawing an input voltage of +24 V DC and consuming a total power of 14.4W.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product Code

AKI2G-CDB-MOD-07T-000

Manufacturer

Kollmorgen

Product Type

Graphic Operator Terminal

Series

AKI

Weight

0.8kg

Mechanical Size

204 x 143 x 50 mm

Cutout Size

189 x 128 mm

Housing Material

Powder-coated Aluminium

Touch Screen Material

Resistive, Polyester on Glass with ITO film

Display Type

7” Diagonal TFT-LCD

Display Resolution

800 x 480 pixels

Backlight Type

350cd/m2 LED

Backlight Lifespan

20,000 hours

Processor

Single Cortex-A9

Cache

512 kb L2

Pulse Wave

Up to 1.0 GHz

RAM

512 MB

Flash Memory

2GB SSD (eMMC)

Free Space for Applications

Up to 1.5GB

Communication Ports

9-pin DSUB Serial, 1 x 10/100 Base-T Ethernet (Shielded RJ45)

Expansion Interface

ciX Expansion Module, SD and SDHC Compatibility, 1 x USB Host 2.0

Max Output Current (USB)

500 mA

Operating Temperature

-10o C - 50o C

Storage Temperature

-20o C - 70o C

Relative Humidity

5 % - 85 % Non-condensation

Front Panel Seal

NEMA 4X/12, UL Type 4X/12, IP 65

Rear Panel Seal

IP 20

Input Voltage

+24V DC (18 to 32 V DC)

Power Fuse

Internal DC Fuse

Power Consumption

14.4W
