AKM12C-ANCNR-00

Original price $1,197.00 - Original price $1,197.00
Original price
$1,197.00
$1,197.00 - $1,197.00
Current price $1,197.00
Available, Shipping Varies
Request a quote
The Kollmorgen AKM12C-ANCNR-00 is a high-performing, dynamic synchronous servomotor with a 40mm flange, a rotor length of 2, and C-type winding. The connectors may not be unplugged when the motor is active and must operate within a 5 to 40°C temperature range. The motor features Class F insulation and is designed with rare earth magnets. It has a peak current rating of 6.06A, peak torque rating of 1.08A, and weighs 0.49kg. The rotor inertia is rated at 0.031kgcm2. The IEC-spec flange design incorporates a smooth shaft and a 0.5m shielded cable with IP 65 connectors. The motor should be ceased immediately when bearing noise is heard, which should be checked every 2500 hours, and disposed of through a certified company if necessary. Unauthorized connection to the main supply and physical obstruction might stall the motor rotation. Global delivery is available.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Product Type: Synchronous Servomotor
  • Model: AKM12C-ANCNR-00
  • Series: AKM
  • Flange Size: 40mm
  • Rotor Length: 2
  • Winding Type: C
  • Operating Temperature: 5°C-40°C
  • Insulation Class: F
  • Peak Current Rating: 6.06A
  • Peak Torque Rating: 1.08A
  • Weight: 0.49kg
  • Rotor Moment of Inertia: 0.031kgcm2
  • Flange Design: IEC Specifications
  • Shaft Type: Smooth
  • Cable Length: 0.5m
  • Connectors: IP 65
  • Check Interval: 2500 Operating Hours
  • Disposal: Certified Disposal Company Only
  • Shipping: Worldwide
