AM3073-1Q30-0000
by Beckhoff
The Beckhoff AM3073-1Q30-0000 is a robust servo motor in the AM Synchronous Servo Motors series by Beckhoff. It delivers a rated power of 7.92 kW and a maximum peak torque of 168.0 Nm at a nominal voltage of 480 V AC. Designed for precise motion control and high-dynamic response, this synchronous servomotor is well suited to demanding industrial automation applications requiring accurate positioning and reliable power delivery.
Featuring a rated torque of 25.2 Nm and a standstill torque of 41.6 Nm, the AM3073-1Q30-0000 excels in both continuous and static load conditions. It operates at a rated speed of 3000 min^-1 with a peak current of 122.6 A and a standstill current of 24.60 A. The torque constant of 1.69 Nm/A underscores its efficient conversion of electrical input into mechanical output, while the rotor moment of inertia of 92.0 kgcm² maintains smooth acceleration profiles. The motor is cooled by convection, ensuring thermal stability during extended cycles, and accepts advanced feedback via resolver, BiSS B, and EnDat 2.1 interfaces.
Built to withstand ambient temperatures from +5…+40 °C, this motor delivers durability and operational stability in typical factory environments. The sturdy M40 connection method provides a secure and service-friendly interface for power and signal cabling. With convection cooling, the motor achieves efficient heat dissipation without auxiliary fans, reducing maintenance requirements. The combination of high torque density, advanced feedback options, and precise speed control makes the AM3073-1Q30-0000 an ideal choice for high-performance tasks such as CNC machining, robotics, and conveyor systems, offering enhanced productivity and reduced downtime in industrial installations.
