The ASP-180-18 is a 3-phase MOSFET inverter from Copley Controls’ Accelus Servo Drives series. Featuring sinusoidal field-oriented control, it delivers 6 A continuous and 18 A peak output within a +20 to +180 Vdc input range. Utilizing 20 kHz PWM with space-vector modulation, it offers precise motor control. Integrated HV overvoltage, undervoltage, overtemperature and short-circuit protections ensure robust industrial performance.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Analog Reference Input
±10 Vdc differential, 66 kΩ impedance
Commutation & Control
Sinusoidal FOC of brushless DC motor
Continuous Output Current
6 A DC (4.2 A RMS)
Current Loop Update Rate
20 kHz (50 µs period)
Digital I/O
6 inputs, 2 outputs, programmable
Dimensions
167.1×98.8×29.7 mm (6.58×3.89×1.17 in)
Input Voltage
+20 to +180 Vdc, transformer‑isolated
Peak Output Current
18 A DC (12.7 A RMS)
Protection
HV overvoltage, undervoltage, overtemp, short-circuit
PWM Outputs
3‑phase MOSFET inverter, 20 kHz PWM, SVM
RS‑232 Communication
9600–115200 Baud, full‑duplex
Velocity & Position Loop Rate
4 kHz (250 µs period)
Weight
0.43 kg (0.94 lb)
