AX5103-0000-0200

Original price $2,504.33 - Original price $2,504.33
Original price
$2,504.33
$2,504.33 - $2,504.33
Current price $2,504.33
In Stock, Ships Today
Request a quote
The product featured is the AX5103-0000-0200 servo drive from the AX5000 series by Beckhoff Company. This hardware component is specifically designed for use in machines or electronic systems, contributing to high dynamic positioning and minimizing cycle time when utilized with an EtherCAT system. Marked by a single channel and standard hardware features, it operates at temperatures between 0 to 50 degrees celsius and can withstand up to 95% humidity without condensation. It provides excellent performance at altitudes up to 1000m and maintains adequate performance up to 3000m with power reduction. Its protection rating is IP 20, advising cabinet mounting. Key features include a rated output current of 3A, maximum 7.5A output current, and 3 x 100-10% - 480+10% rated supply voltage. The unit measures 274(H) x 92(W) x 2312(D) mm and weighs approximately 4kg. Suited for speed, torque, and position control of motors, it must only be operated as part of a machine or system and installed within a control cabinet.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff Company
  • Product Type: Servo Drive
  • Series: AX5000
  • Design: Component of a machine or electronic system
  • Function: Positioning and cycle time reduction
  • Channels: Single
  • Hardware: Standard
  • Operating Temperature: 0 to 50 degrees
  • Transport and Storage Temperature: -25 to 70 degrees
  • Relative Humidity: 5% to 95% without condensation
  • Maximum Installation Height: 1000 meters without reduced power, 3000 meters with reduced power
  • Protection Class: IP 20
  • Rated Output Current: 3A
  • Maximum Output Current: 7.5A
  • Rated Supply Voltage: 3 x 100-10% - 480+10%
  • Power Dissipation: 50W
  • Communication System: High-speed EtherCAT
  • Motor Type: Flexible Selection
  • Display: Parameter and Diagnostic
  • Dimensions: 274(H) x 92(W) x 2312(D) mm
  • Weight: 4kg
  • Control: Speed, Torque, and Position
  • Usage: Part of an electrical machine or system
  • Housing: Pre-determined required
