series image of AX5203-0000-0202

AX5203-0000-0202

by Beckhoff
$0
$5,777.92 - $5,777.92
$5,777.92
$5,777.92 - $5,777.92
$5,777.92
In Stock, Ships 3 - 5 Days
 More payment options
The AX5203-0000-0202 is a compact digital servo drive manufactured by Beckhoff, a leading provider of open control automation solutions. As a member of Beckhoff's AX5000 series, this servo drive is designed for superior performance and cost-effectiveness, and meets the needs of a variety of applications, from CNC-controlled machine tools to full-scale automated operations. The AX5203-0000-0202 features high-speed EtherCAT system communication, multi-feedback interface, flexible motor type selection, active DC-link and brake energy management, and high-speed capture inputs. It also includes safety-oriented features, such as TwinSAFE safety functions and optional STO and SS1. This servo drive operates on a rated supply voltage of 3 x 100…480 V AC ±10 % and has a protection class of IP 20. Its power loss is 85 W, with a DC-link capacitance of 235 µF.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Product Family: AX5000
  • Model: AX5203-0000-0202
  • Communication System: EtherCAT
  • Energy Management: Active DC-link and brake
  • Interface Type: Multi-feedback
  • Cooling Concept: Optimized
  • Built-in Safety Features: TwinSAFE safety functions
  • Optional Safety Functions: STO and SS1
  • Rated Supply Voltage: 3 x 100…480 V AC ±10 %
  • Rated Output Current per Axis: 3 A
  • Maximum Configurable Rated Output Current: 4.5 A
  • DC-link Capacitance: 235 µF
  • Power Loss: 85 W
  • Protection Class: IP 20
  • Approvals: cULus, EAC and CE
  • Hardware Version: 2.0
  • Firmware Version: ≥ 2.10
  • Additional Brake Module Unit: Internal braking possible
