AX5203-0000-0200

Original price $3,408.75 - Original price $3,408.75
Original price
$3,408.75
$3,408.75 - $3,408.75
Current price $3,408.75
In Stock, Ships Today
Request a quote
The Beckhoff AX5203-0000-0200 is a high-speed, dual-channel digital servo drive from their reputable AX5000 series. It features EtherCAT system communication, a multi-feedback interface, and quick-capture inputs. Its notable characteristic is the integrated AX bridge, allowing swift links for DC-link, control voltage, and power supply along with a diagnostic and parameter display. The design optimizes cooling, ensuring efficient operation without overheating, even under full load. It operates across a broad voltage range and has a rated current within 2 x 1.5 A to 2 x 6 A. Other technical specifics include a DC-link capacitance of 235 µF, power loss at 85 W, and an operating ambient temperature of 0°C to 55°C. This servo drive conforms to a SERCOS drive profile per IEC 61800-7-204 standards, and has approvals from cULus, EAC, and CE. It can house an additional DC-link expansion for effective brake energy storage.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Product Series: AX5000
  • Model: AX5203-0000-0200
  • Type: Dual-Channel Digital Servo Drive
  • System Communication: EtherCAT
  • Feedback Interface: Multi-feedback interface
  • Capture Inputs: High-Speed
  • Additional Features: AX bridge, Diagnostic and Parameter Display
  • Design: Cooling optimized
  • Voltage Range: 1 x 100V-240 V AC ±10 % and 3 x 100V-480 V AC ±10 %
  • Rated Current: 2 x 1.5 A, 2 x 3 A, 2 x 6 A
  • DC-link Capacitance: 235 µF
  • Power Loss: 85 W
  • System Bus: EtherCAT
  • Drive Profile: SERCOS (IEC 61800-7-204)
  • Operating Temperature Range: 0°C to 55°C
  • Certifications: cULus, EAC, CE
  • Hardware Version: 2.0
  • Firmware Version: ≥ 2.10
  • Additional Supported Component: DC-link Expansion
