S image of B-206-B-33-B3

B-206-B-33-B3

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The Kollmorgen B-206-B-33-B3 is part of their B series servomotors, designed for use with a SERVOSTAR digital amplifier. High energy, rare earth magnets are housed inside, with standard models featuring industrial-grade connectors and a built-in frameless resolver. Other product features include a rear shaft extension and an integral thermostat. The servomotor’s performance, including its velocity, torque, and stored motor parameters, can be monitored using Kollmorgen's MOTIONLINK software. Its maximum allowed pressure on the motor shaft seal is 0.21kg/cm2. Operating at ambient temperatures of 40°C or lower, the motor is equipped with Class H insulation and offers a line-to-line back EMF of 130 +/-10% V/kRPM, and a continuous line current rating of 5.8A. This frame size 20 servomotor can be conveniently mounted in both vertical and horizontal orientations, and is offered with worldwide shipping.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Model

B-206-B-33-B3

Motor Series

B Series

Compatible Amplifier

SERVOSTAR Digital Amplifier

Motor Magnets

Rare Earth High Energy Magnets

Connector Type

Industrial-Grade Connectors

Built-in Features

Integral Frameless Resolver, Rear Shaft Extension, Inbuilt Thermostat

Motor Monitoring Software

MOTIONLINK

Shaft Seal Pressure Tolerance

0.21kg/cm2

Mounting Hole Diameter

0.276 inches

Mounting Orientation

Vertical and Horizontal

Current Rating

18A Peak

Motor Inertia

0.00025kgm2

Operating Ambient Temperature

40°C or Less

Insulation

Class H

Back EMF

130 +/-10% V/kRPM

Continuous Line Current Rating

5.8A

Frame Size

20

Motor Coding

Frameless Resolver

Control Options

PDFF, PI and Pole Placement

Motor Winding Check Feature

Auto-Configuration Function in MOTIONLINK Software

Shipping

Worldwide
