S image of B-206-C-21

B-206-C-21

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The Kollmorgen B-206-C-21 is a compact, brushless servomotor that utilizes high-energy neodymium-iron-boron rare earth magnets. Known for its low inertia, the B series motor works hand in hand with Kollmorgen's SERVOSTAR SR10 servoamplifier to deliver a high-performance motion control system. The motor features unterminated flying leads for connection, a continuous current and power rating of 10ARMS and 3.8HP respectively, and a peak current rating of 20ARMS per phase. The servoamplifier offers circuit protection and a 12-bit input resolution. Specifically, the unit provides safeguards against overvoltage, undervoltage, short circuits, feedback loss, overcurrent, and overspeed. Thanks to its resolver feedback system and an operating temperature up to 40°C, this product ensures reliable performance. The motor can sustain a speed of up to 4,900RPM, meets IP 65 sealing standards, and is ideally connected to the servoamplifier via manufacturer-provided CS-SS-RGA 12-xx cable.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Series

B

Product Model

B-206-C-21

Design

Thermal design without brushes

Size

Compact

Motor Magnets

Neodymium-iron-boron rare earth

Motor Stack Length

6

Winding Code

C

Leads Type

Unterminated flying leads

Leads Length

Minimum 18 inches

Thermal Time Constant

22 minutes

Feedback

Resolver

Continuous Current Rating

10ARMS

Peak Current Rating

20ARMS

Continuous Power Rating

3.8HP

Servoamplifier Input Resolution

12-bit

Protection

Short circuits, feedback loss, undervoltage, overvoltage, overcurrent, overspeed

Ambient Operating Temperature

40°C max

Rated Speed

4,900RPM

Shaft Seal

IP 65

Motor Connection Cable

CS-SS-RGA 12-xx

Resolver Frame

Absent

Brand

GOLDLINE

Servoamplifier Enclosure

Fully metallic

ESD Circuit Design

Rugged

Amplifier Auto-setup

Five step configuration.
