S image of B-604-B-91-B3R500-008

B-604-B-91-B3R500-008

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The B-604-B-91-B3R500-008 is a compact, low-inertia servomotor produced by Kollmorgen. It stands out for its remarkable thermal construction, capable of delivering continuous and peak torque. The servomotor leverages a Windows-based MOTIONLINK software to interface with its servo amplifier. The device comes equipped with an inertia of 0.00203 kgm2, along with a line-to-line inductance of 13.3mH. The unit also possesses a torque sensitivity of 1.09 +/-10% Nm/ARMS, and a shaft diameter of 23.996mm. Additional vendor offerings include the availability of feedback options like resolver and encoder adapter and a smooth speed control DC tachometer. The square-framed servomotor, without a front shaft seal, has been designed for standard metric mounting with perpendicularly-oriented thread connectors. The special code 008 denotes the presence of a specific adapter or receiver.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Type

Servomotor

Model Number

B-604-B-91-B3R500-008

Thermal Design

Capable of rendering continuous and peak torque

Software Configuration

Windows-based MOTIONLINK software

Operating Modes

Torque control and velocity control

Inertia

0.00203 kgm2

Line-to-line Inductance

13.3mH

Torque Sensitivity

1.09 +/-10% Nm/ARMS

Shaft Diameter

23.996mm

Mounting Holes

Four, 11mm each

Motor Length Increase with Resolver

2.80 inches

Motor Length Increase with Encoder Adapter

1.17 inches

Tachometer

DC, 0.6% average to peak voltage ripple

Delivery

Worldwide

Frame Size

60

Winding Type

B

Stack Length

4

Connectors

Standard thread with mating plugs

Mounting Style

Standard metric

Front Shaft Seal

Absent

Sequential Special Code

008

Adapter/Receiver

Special.
