The B-606-DD-99-TS-268, a GOLDLINE brand servomotor from Kollmorgen, is designed for high-response applications. Ideal for compact spaces, this motor possesses continuous and peak line current ratings of 28ARMS and 86.2ARMS, respectively. It features a winding type D, brush tachometer winding type D, and an IP 65 protection rating. The attached amplifier monitors the power applied to the motor and can be toggled on or off. This device operates best when utilized in conjunction with the SR30 digital servo amplifier made by Kollmorgen. With a peak torque rating of 123Nm, it can be mounted using a the metric mounting style and tolerates a maximum line-to-line voltage of 250VRMS. This model also includes a brushless design, a thermal time constant of 38 minutes, and an allowance for a low-backlash gearhead for precise positioning.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Product Line: GOLDLINE
  • Servomotor Type: B-606-DD-99-TS-268
  • Continuous Line Current Rating: 28ARMS
  • Peak Line Current Rating: 86.2ARMS
  • Winding Type: D
  • Brush Tachometer Winding Type: D
  • Protection Rating: IP 65
  • Feedback Type: Resolver
  • Size: Compact
  • Functionalities: Amplifier Monitoring, Digital Oscilloscope Function, Programmable Thermostat
  • Peak Torque Rating: 123Nm
  • Mounting Style: Metric
  • Best Paired Amplifier: SR30 digital servo amplifier
  • Mounting Requirements: 300-in2 x 3/4-inch aluminum faceplate
  • Maximum Line-to-Line Voltage Rating: 250VRMS
  • Thermal Time Constant: 38 minutes
  • Viscous Dampering Z Source: 0.147Nm/kRPM
  • Additional Features: Brushless Design, Supports Gearhead Use, Status Storage in Servo Amplifier
