S image of B-806-AA-91-TR517-008

B-806-AA-91-TR517-008

by Kollmorgen
$3,375.00 - $3,375.00
$3,375.00
$3,375.00 - $3,375.00
$3,375.00

In Stock, Ships 1 - 3 Days

The B-806-AA-91-TR517-008 servomotor is a high-quality product from Kollmorgen, designed for point-to-point move applications. Fitted with sturdy frameless resolvers for feedback and a brush tachometer, this servomotor operates at a maximum ambient temperature of 40°C. It is designed to work with the SR30 digital servo amplifier from Kollmorgen and is a remarkable example of low inertia servomotors in the B series. Notable features include high-energy neodymium-iron-boron magnets, high power and torque density, square frame size of 80, compact thermal design, and metric mounting style. The static friction stands at 1.38Nm and power rating at 20.5HP. The motor has an IP 65 protection rating and utilizes uniquely designed connectors. The unit also extends its functionality with a torque sensitivity of 2.21 +/-10% Nm/ARMS during stall, houses three pairs of poles and offers smooth speed control at slow speeds.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Code

B-806-AA-91-TR517-008

Type

Servomotor

Features

High-energy rare-earth magnets, rugged frameless resolver, brush tachometer

Compatibility

SR30 digital servo amplifier

Design

Low inertia, high power and torque density, interior permanent magnets

Frame Size

80 square

Thermal Design

Compact

Tachometer Winding

A

Winding Type

A

Static Friction

1.38Nm

Power Rating

20.5HP

Brand

GOLDLINE (motor), SERVOSTAR (digital amplifier)

Mounting Style

Metric

Stack Length

2

Protection Rating

IP 65 for shaft seal

Connectors

Special

Torque Sensitivity

2.21 +/-10% Nm/ARMS (at stall)

Pole Pairs

3

Special Code

008

Tachometer Pins

2 (Black and white)

Ripple

0.6% average to peak voltage

Additional Attribute

Smooth speed control at very slow speeds

Motor Length Increase

56.4mm (due to DC tachometer)
